Rich Solar SKU: RS-MPPT50DC Barcode: 650380716314

Description

Features

  • Can connect to PV and alternator
  • Charges both leisure and starter battery
  • MPPT with up to 99.9% efficiency
  • Supports TTL communication

Specifications


PV INPUT

Max. Voltage of Open Circuit: 55Vdc

MPPT Voltage Range: 17-36Vdc

Max PV Input Current: 45A

Max PV Input Power: 800W

BATTERY TYPE - Li-ion / Lead Acid / User Defined

Rated Battery Voltage: 12Vdc

Battery Voltage Range: 9-17Vdc

Max MPPT Charging Current: 50A

Max Alternator Charging Current: 60A

MPPT Charging Mode: Buck

BATTERY TYPE - Lead Acid

Rated Battery Voltage: 12Vdc

Max MPPT Charging Voltage: 13.8V

Max MPPT Charging Current: ≤25A

Max Alternator Input Voltage (Conventional): 13.2-16Vdc

Max Alternator Input Voltage (Euro 6 Standard): 12-16Vdc

Alternator Charging Mode: Buck, Boost, Buck-Boost

EFFICIENCY

MPPT Tracking Efficiency: >99%

Max Charging Conversion Efficiency: 98%

COMMUNICATION

Embedded Interfaces: TTL, Remove Switch

GENERAL

Weight: 4.7 lbs

Dimensions: 8.7 x 6.9 x 3.2 inches

Protection Degree: IP32

Operating Temperature Range: -35°C~65°C(-31℉~149℉)

CERTIFICATION

Safely: IEC62109

EMS: IEC61000, FCC sDoC

Rohs: YES

User Manual

Rich Solar Warranty, Shipping, and Refunds

3 in stock! Additional is backordered

$249.99

Shipping calculated at checkout

 More payment options
4.6 7+ online reviews

4.6

7+ online ratings
The summary star rating & review is based on aggregated reviews of this product across the web. It cannot be altered by the merchant and can be verified by emailing support@onereview.app.

BRAVO 50 DC | 50 Amp DC-DC Solar Charge Controller with MPPT | Premium 50A 12V/24V DC-DC Solar Controller with MPPT for RVs, Trailers, Campers, Vans, Boats, Off-Grid | #1 Ranked DC to DC Solar Controller Review Summary

4.6

7+ online ratings
The summary star rating & review is based on aggregated reviews of this product across the web. It cannot be altered by the merchant and can be verified by emailing support@onereview.app.

What people like

Reviews for the Rich Solar BRAVO 50 DC charge controller generally highlight its ease of installation and effective MPPT charging capabilities. Users appreciate its ability to efficiently charge batteries from solar panels, especially in RV, camper, and off-grid applications. Some reviews also mention the clear display and robust build quality, while others point out minor issues with the manual or specific configuration needs.

Pros

  • Easy Installation: Many users found the controller relatively easy to install and set up.
  • Efficient Charging: The MPPT (Maximum Power Point Tracking) is often praised for its ability to efficiently charge batteries.
  • Clear Display: Several reviewers appreciate the clear and informative display.
  • Solid Build: Some users noted the robust and durable build quality of the unit.
  • Versatile Applications: Suitable for RVs, campers, boats, and off-grid systems.

Cons

  • Manual Clarity: Some users found the manual lacking in detail or clarity.
  • Configuration Needed: Some configurations require more technical knowledge.
  • Fan Noise: The fan can be noisy for some users, especially in quiet environments.
  • Limited Support: A few users have mentioned difficulties reaching customer support.
